Specifications
| Stock Number | BA9-1006140 |
|---|---|
| Bed Height (In.) | 12.20″ |
| Center Height | 7.086 |
| Compound Rest Width | 4.33 |
| Compound Slide Travel (In.) | 4.75″ |
| Range of Cross Feeds (MMPR) | 40 / .015 – .320 mm / rev. |
| Cross Slide Travel (In.) | 9 |
| Cutting Tool Max Section | .625″ x .625″ |
| Distance Between Centers (In.) | 40″ |
| Input Power | 220V / 3-phase |
| Lead Screw Diameter | 1.25 |
| Leadscrew Thread Pitch | 4 T.P.I. |
| Longitudinal Feeds Imperial Qty Speed | 40 / .0012″ – .0252″ / rev. |
| Longitudinal Feeds Metric Qty Speed | 40 / .032 – .640 mm / rev. |
| Quill Taper | Morse #6 |
| Shipping Dimensions (L x W x H) (In.) | 90x37x81 |
| Spindle Bore (In.) | 2.0625″ |
| Spindle Taper with Sleeve | Morse #4 |
| Swing Over Bed (In.) | 16″ |
| Swing Over Cross Slide (In.) | 9.45″ |
| Swing Through Gap (In.) | 23.42″ |
| Table Length (In.) | 74.75″ |
| Tailstock Spindle Travel (In.) | 4.75″ |
| Taper in Tailstock Spindle | 2.125″ |
| Weight (Lbs.) | 3940 |
| Width of Bed (In.) | 11.81″ |
| Speed (rpm) | 30 – 2000 rpm |
| Threads Diametrical Quality Speed (D.P.) | 32 / 4–32 D.P. |
| Threads Imperial Quality Speed (T.P.I.) | 40 / 2–56 T.P.I. |
| Threads Metric Quality Speed (mm pitch) | 53 / .4–14 mm pitch |
| Threads Modular Quality Speed (M.P.) | 44 / .4–7 M.P. |
